Name: Philips 22AH170 FM / AM Tuner
Brand: Philips
SKU: 20483
Price: 119.00 EUR
Availability: OutOfStock

650+ PRODUCTS IN WEBSHOP • WORLDWIDE SHIPPING FROM THE NETHERLANDS

Sold out

€ 119.00

Analog vintage Philips 22AH170 FM / AM tuner with illuminated tuner scale. The Philips 22AH170 tuner matches the Philips 22AH270 and 22AH280 preamplifier, the 22AH370 and 22AH370 power amplifier, the 22AH180 tuner, the 22AH070 switch unit, the 22AH080 tim

Add to Wish List

Compare this Product

Ex Tax: € 119.00

Availability: Out Of Stock

Brands Philips

Product Code: 20483

Tags: Philips 22AH170 Tuner Philips 170 Tuner 22AH170 170 22AH Philips AH Philips 22AH Philips AH170 22AH170/22 Philips Tuner Philips Radio Tuner Philips 22AH170 Specifications Specs Specifications Radio Black 19 Inch Vintage Audio Vintage Audio Vintage Philips HiFi Stereo

Description
Specifications

Specifications Philips 22AH170 tuner:
- Type: Mono/Stereo Tuner
- Tuning Bands: FM, MW, LW
- FM Tuning Range: 87.5 to 108 MHz
- MW Tuning Range: 520 to 1605 kHz
- LW Tuning Range: 150 to 255 kHz
- Sensitivity: 80uV (FM), 90uV (MW), 90uV (LW
- Signal to Noise Ratio: 46dB (FM), 26dB (MW), 26dB (LW)
- Output: 1100mV (FM), 600mV (MW), 600mV (LW)
- Dimensions (W x H x D): 482 x 78 x 280 mm

Product:
Analog vintage Philips 22AH170 FM / AM tuner with illuminated tuner scale.

The Philips 22AH170 tuner matches the Philips 22AH270 and 22AH280 preamplifier, the 22AH370 and 22AH370 power amplifier, the 22AH180 tuner, the 22AH070 switch unit, the 22AH080 timer and the N2537, N5438 and N5758 cassette deck.

Please note:
The photos are from a similar Philips 22AH170 tuner. Photos of the actual Philips 22AH170 tuner for sale will follow soon.

Condition:
Technical condition: 10 / 10
Cosmetic condition: 7 / 10

Electric power requirements:
Input voltage: 220 V
Input frequency: 50 / 60 Hz
